Modular design
The structure of the system is completely modular and consists
of a bridge module and up to 12 axis modules.
The connection to the servo controllers is made with standard RJ45 cables.
Certified safety functions
All safety functions are handled independently with the servo controllers.
This means that no programming of the actual safety functions is required.
This is so important because such programming in terms of safety regulations
would require time-consuming validation of proper function.
Simple coupling with safety controllers
When connecting to safety controllers, special emphasis was placed on
the fact that as few signals as possible are required.
This goal is achieved by forming groups of several axes in the bridge
module, which are controlled by common signals. If, for example, the
safety function SLS is to be used on 6 axes, then only a single input
is required for this purpose. Conversely, it is signaled via an output
that all 6 axes work without interference.
|
